产品说明:
选用水基加少许添加剂作为清洗剂,成本低廉,清洗效果好,是最理想最实惠的清洗设备
● 适用范围:该款清洗机主要用于汽车零部件、空调压缩机零部件、汽车空调管组件(铝管,铜管)家用空调管组件(铜管、铝管)内外壁的的油污和金属削的清洗。保证这些零件装配前的清洁.
● 工业流程1:超声粗洗→ 超声精洗→防锈漂洗→ 吹干+烘干
工艺流程:2:超声脱脂清洗→液下水射流漂洗→市水鼓泡漂洗→ 磷化→市水漂洗→热纯水漂洗→吹干+烘干
材质及结构
* 全进口加厚不锈钢耐酸碱,美观耐用
* 高Q值压电晶体换能器,超声功率强劲
* 自动加热、循环过滤
* 摆动设计,增加清洗效果
4-slot Series Ultrasonic Cleaning Machines :use water-based solvent with a little additive as the cleaner, which is cheap and effectual . It is the most ideal cleaning equipment .
● Application : Electronic part , non-electroplating one , hardware, clock and watch , machinery , watchband , tool , medium and small-scale bearing and glass ware ,etc.
● Washing process: Ultrasonic washing(swing) →Ultrasonic fine washing (swing) →Ultrasonic rinsing (swing) →Drying
●Feature :
* Import and thicken stainless steel , resist-acid and alkali, attractive and durable ;
*USA high-Q value oscillator , powerful
* Heat automatically, circulation is filtered
* Swing and design, increase the result of washing
Lntegrative structure practicing thrift in the space
● 技术规格Technical specification
工作频率Ultrasonic frequency(KHz): 22KHz、25KHz、28KHz、40KHz
超声波功率Ultrasonic power(w):: 1500/1800W
电加热管功率Heat the power: 3KW
清洗槽内净尺寸Wash trough net size: 590mm×400mm×400mm
清洗篮尺寸(可定制)basket of size(can be customized)::400mm×300mm×250mm
电源: 380±10V,三相四线Power: 380±10V,four lines of three-phase
以上工艺流程和相应的参数可以根据客户的要求制做
